Connecting a heat pump to an existing system – how to upgrade?

Integrating a heat pump with an existing heating system is an effective way to increase a building’s energy efficiency and reduce heating costs. For the retrofit to deliver the expected results, careful planning of the entire process and adapting modern technology to the existing system are crucial. How can this be done? Here are the most important aspects to consider. Why is it worth connecting a heat pump? Above all, because of its ability to efficiently extract energy from the surroundings and convert it into heat. This solution is not only environmentally friendly, but also financially beneficial. However, in order to fully use its potential, the existing heating system must be properly adapted. Retrofitting the system is not only a technical challenge, but also a financial one. It is worth checking available forms of support, such as grants or tax reliefs, which can significantly reduce investment costs. In the United Kingdom (UK), grant programmes and other forms of support may be available – it is worth verifying the current terms and criteria in order to realistically reduce the cost of the investment. When planning the retrofit, it is crucial to determine which parts of the installation require adaptation. Older heating systems may require:

1. Replacing radiators with models designed for lower operating temperatures.
2. Upgrading pipework to ensure optimal heat pump performance.
3. Assessing the condition of the hydraulic and electrical installation by a specialist.

Connecting a heat pump to an existing system is a step towards more sustainable and cost-effective energy management. In addition, modern technologies such as smart heating management systems can further increase the efficiency of the entire system. Good preparation for a retrofit will help avoid surprises and fully utilise the potential of modern heating solutions.

On stock

Plate Heat Exchanger NORDIC Ba-95-30 2" 700kW

NT Ba-95-30

€599.99

Add to basket

On stock

Plate Heat Exchanger NORDIC Ba-95-60 2" 1500kW

Exchanger-BPHE-Ba-95-60

€1,075.00

Add to basket

On stock

Plate Heat Exchanger NORDIC Ba-60-60 1 1/4" 660kW

NT Ba-60-60

€525.00

Add to basket

How do you prepare an installation for connecting a heat pump?

Preparing an installation for a heat pump is a key stage that requires taking into account both technical requirements and the specifics of the existing heating system. To ensure maximum energy efficiency, it is worth starting with an energy audit. This is a detailed analysis that makes it possible to determine the building’s heat demand and identify potential heat losses – this information is essential before upgrading the heating system. An energy audit is not merely a formality, but the foundation of an effective heat pump installation. It makes it possible to precisely identify which elements of the system require modernisation in order to adapt them to new technical requirements. Particular attention should be paid to:

1. Quality of thermal insulation – poor insulation leads to major heat losses.
2. Condition of the pipework – leaks can reduce system efficiency.
3. Performance of the existing radiators – older models may not be suitable for operating with a heat pump.

Only after such an analysis can you be sure that the heat pump will operate with optimal efficiency, providing thermal comfort with minimal energy consumption.

On stock

Plate Heat Exchanger NORDIC Tec Ba-27-90 1 1/4" 500kW

EU-NT Ba-27-90

€449.99

Add to basket

On stock

Plate Heat Exchanger NORDIC Ba-27-70 1 1/4" 390kW

NT Ba-27-70

€369.99

Add to basket

On stock

Plate Heat Exchanger NORDIC Ba-32-30 1" 175kW

NT Ba-32-30

€173.99

Add to basket

Building thermal retrofit and heat pump efficiency

A building thermal retrofit has a huge impact on heat pump efficiency. Good thermal insulation reduces heat losses, which translates into more efficient heating and lower running costs. Before connecting a heat pump, it is worth considering:

1. Insulating external walls – reduces heat loss through the building envelope.
2. Replacing windows with energy-efficient models – reduces heat losses through glazing.
3. Upgrading the roof – improves the thermal insulation of the entire building.

Thermal retrofit works carried out before installing a heat pump not only increase the efficiency of the heating system, but also significantly reduce heating bills. A well-insulated building retains more heat, which means that the heat pump uses less energy to maintain a comfortable indoor temperature. This is not only a saving, but also a step towards more ecological and sustainable energy management.

Selecting the right heat pump for an existing installation

Choosing a heat pump for an already operating heating system is a key step towards energy efficiency and thermal comfort in the building. For the system to operate optimally, several important factors must be considered: the type of the current installation, the heat demand, and the specifics of the building itself. A thorough analysis of these aspects helps avoid unnecessary costs and ensures maximum performance. First, it is worth determining which type of heat pump will be the best solution. Options include air-to-water heat pumps and ground source heat pumps, which differ in the way they obtain energy. Each of these solutions has its advantages and limitations, so it is crucial to match the technology to the building conditions and the characteristics of the existing installation. A heat pump can work with both underfloor heating and traditional radiators. Choosing the right model should take these aspects into account to ensure efficient and economical heating. An important parameter is also the unit output – too low may not provide adequate thermal comfort, while too high will increase running costs. Therefore, before making a decision, it is worth consulting an expert who will help select the optimal solution.

High-temperature heat pump – when is it needed?

A high-temperature heat pump is an ideal solution for buildings fitted with cast iron radiators, which require a high flow temperature. Standard heat pumps often do not reach temperatures around 80°C, which is necessary for the efficient operation of older heating systems. In such cases, a high-temperature heat pump allows the heating to be modernised without having to replace the entire installation. Connecting a heat pump to an existing heating system requires adapting the system operating parameters. In many cases, an additional heat exchanger is also used (e.g. a dedicated plate heat exchanger for a heat pump), which enables effective separation of the system circuits and ensures their optimal cooperation. High-temperature models work particularly well where upgrading the entire system would be expensive or difficult to carry out. This makes it possible to significantly improve a building’s energy efficiency while avoiding major expenses for radiator replacement. If there are cast iron radiators in the building, it is worth considering a high-temperature heat pump. Before making a decision, it is best to consult an expert who will assess whether such a solution will be the most efficient and economical. Choosing the right unit will ensure not only comfortable heating, but also optimised running costs.

Which elements of the installation require adaptation?

When upgrading a heating system to integrate it with a heat pump, it is worth paying attention to several key elements. One of these is a buffer tank, which acts as an energy store. Its role is to stabilise heat pump operation and increase the efficiency of the entire system. Thanks to it, the unit operates under optimal conditions, which translates into lower energy consumption and a longer system service life. Another important element is a magnetic filter, which protects the installation from metallic contaminants. Such deposits can lead to heat pump faults, so the filter effectively eliminates them, ensuring trouble-free system operation. Installing it is a simple but key step that significantly affects the durability of the entire installation.

Underfloor heating and a heat pump – the perfect combination?

Underfloor heating and a heat pump are a solution that provides performance and comfort. Thanks to its low-temperature nature, heat is distributed evenly, which increases user comfort. A heat pump, delivering heat at a lower temperature, works perfectly with this system, ensuring high energy efficiency. Retrofitting the installation and installing underfloor heating is not only energy saving, but also an improvement in interior aesthetics. The lack of traditional radiators means greater freedom in interior design. In addition, this system is allergy-friendly, because it does not cause dust to circulate, which often happens with classic convector radiators.

Convector and cast iron radiators – do they work with a heat pump?

Convector and cast iron radiators can operate in a system with a heat pump, but they require appropriate adaptation. Modern convector radiators can work efficiently in such a setup, provided the flow temperature is reduced. It is worth using temperature controls that allow precise adjustment of operating parameters. Cast iron radiators, due to their design, require a higher flow temperature. In such cases, it may be necessary to use a high-temperature heat pump. Alternatively, it is worth considering replacing radiators with models better suited to low-temperature heat sources, which over the longer term will allow energy savings.

Heat pump operating modes – which one to choose?

Choosing the right heat pump operating mode is crucial for energy efficiency and thermal comfort in the building. There are three main options available: monovalent, mono-energetic and bivalent. Each works best in different conditions, so it is worth becoming familiar with their specifics before making a decision.

• Monovalent mode means that the heat pump is the only heating source. This is an ideal solution for regions with a mild climate, where temperatures rarely drop below zero. In such conditions, the unit operates with maximum efficiency because it does not require support from additional heating systems. The result is lower running costs and simpler operation.
• Mono-energetic mode involves the heat pump working together with electric heaters, which switch on at very low temperatures. This is a good solution for areas with harsh winters, where the heat pump alone might not provide sufficient thermal comfort. Thanks to this mode, the unit is not excessively loaded, which translates into a longer service life and greater reliability.
• Bivalent mode assumes the heat pump works together with another heat source, for example a gas or oil boiler. This is a flexible solution that allows optimal use of different energy sources depending on weather conditions and heat demand. On warmer days the heat pump operates on its own, and on colder days it is supported by an additional heating system, ensuring stability and heating efficiency.

The decision on the heat pump operating mode should take into account the climate, the building characteristics and the users’ needs. It is worth consulting a specialist to match the system to local conditions and ensure maximum energy efficiency.

The cost of connecting a heat pump to an existing installation

Retrofitting a heating system by connecting a heat pump is an effective way to reduce heating bills. However, before making a decision, it is worth analysing the budget carefully, because the connection cost depends on many factors that can significantly affect the final investment price. One of the key aspects is the technical condition of the existing installation. Older heating systems often require replacement of some components, such as radiators, pipework, or even the entire hydraulic infrastructure, which can increase the overall project cost. In addition, installation costs vary depending on the type of heat pump – ground source, air source, or water source. Each of these systems has different technical requirements, which directly affects installation costs. It is also worth taking into account available forms of funding. In the United Kingdom, support programmes for heat pump installations are in place – it is worth checking the currently available options and conditions, which can significantly reduce the heat pump cost. Using such support not only reduces initial expenditure, but can also speed up the return on investment. You should not forget additional expenses such as an energy audit or possible building thermal retrofit. Although they increase the initial outlay, over the longer term they improve system efficiency and generate greater savings. The final retrofit cost depends on many factors – from the building’s technical condition to available forms of financial support. Therefore, before making a decision, it is worth analysing all options so that the investment is as beneficial as possible.

Grants and support schemes – how can you obtain financial support?

In the United Kingdom, support schemes may be available for replacing heat sources and improving a building’s energy efficiency. The scope and conditions of funding depend on current rules and location, so before upgrading it is worth checking the latest criteria and requirements.
