Big Plate Heat Exchanger with 130 Plates 2" NORDIC TEC Ba-115-130

Big Brazed Plate Heat Exchanger - BPHE with 130 plates and connections 2" by Nordic Tec

  • Plate Number: 130 pcs.
  • Connections: 2", external thread
  • Heat Exchange Area: 14.95 m²
  • Gross Weight (Heat Exchanger with a package) - 79 kg
  • Optionally with Insulation Jacket

Brazed plate heat exchanger with a large plate surface area – almost 15 m² – and 2-inch connections.

✅The 130-Plate Heat Exchanger requires a palletized delivery. Delivery is possible in every country in Europe.

✅ Contact us and give us the delivery ZIP Code and a Country to receive the pricing of shipment.

Reference: EU-NT Ba-115-130
Condition New
On stock
€2,169.99
VAT included


Plate Heat Exchanger with Large Heat Transfer Area Nordic Tec Ba-115-130 - 4x 2", 130 plates

Big heat Exchanger - BPHE Nordic Tec Ba-115-130 with a large heat transfer area of about 15m²

130 Plates - Plate Heat Exchanger for heating and cooling 2"

Brazed plate heat exchanger with 130 plates by Nordic Tec, designed for large-scale applications, featuring a large heat exchange surface and 2" diameter connections.
Primarily used in large systems with heat pumps, including low-temperature systems.



Technical details:


- Stainless Steel S316L, brazed with 99,9% Cu

- Connections: 4x 2", BSP

- Working Pressure - up to 30 bar

- Test Pressure - 45-60 bar

- Max. temperature +230°C

- Flowrate - 45 m³/h

Heat Transfer Area of a 130-plate heat exchanger - 14.950 m²


Plate Heat Exchanger 130 plates transfer area


Dimensions:


Heat Exchanger Size Ba-115-130

A - 535 mm
B - 253 mm
C - 456 mm
D - 174 mm
F - 330 mm

EU-NT Ba-115-130
